How to Start Easy Wireless Connect - G4210

Printable View
« Go Back

Information


TitleHow to Start Easy Wireless Connect - G4210
URL NameART169354
Description
This article explains how to place the PIXMA G4210 in its Easy Wireless Connect setup mode.


Solution
To place your PIXMA G4210 into Easy Wireless Connect mode, follow the steps listed below.


  1. Press the Setup button (A) on the printer.

    figure: Press the Stop button

  2. Select Wireless LAN and press the OK button.

    Select conn. method screen: Select Wireless LAN

  3. Select Yes and press the OK button.

    Select conn. method screen: Select Yes

  4. Select Easy WL connect and press the OK button.

    Select setup method screen: Select Easy WL connect

  5. When the printer preparation is complete, the screen below appears.

    Return to the application screen and proceed with the setup.

    It may take time until the printer is detected and the screen changes.

    Easy WL connect screen: Follow the instructions on the PC or smartphone, etc.



PIXMA G4210 Page
